Parting,Grooving
Main Application

Related Insert Related Tool

Product No.

Designation

OAL

CDX

Screw

Wrench

Hand

DCON

DMIN

Insert type

T2421109 MPNHR16-2 2.0 125.0 16.5 1.8 8.5 MWM0501 ML05 R 16.0 - 7.5 25.0 MPCN200C02-TX5020

T2421110 MPNHR20-2 2.0 160.0 15.8 1.6 6.0 MWM0502 ML05 R 20.0 40.0 9.0 25.0 MPCN200C02-TX5020

T2421111 MPNHR25-2 2.0 200.0 17.5 1.6 5.0 MWM0503 ML05 R 25.0 40.0 11.5 25.0 MPCN200C02-TX5020

T2421112 MPNHR32-2 2.0 250.0 20.8 1.5 4.7 MWM0503 ML05 R 32.0 60.0 14.0 31.0 MPCN200C02-TX5020

T2421113 MPNHR20-3 3.0 160.0 15.8 2.1 6.0 MWM0502 ML05 R 20.0 40.0 9.0 25.0 MPCN300C02-TX5020

T2421114 MPNHR25-3 3.0 200.0 17.5 2.1 5.1 MWM0503 ML05 R 25.0 40.0 11.5 25.0 MPCN300C02-TX5020

T2421115 MPNHR32-3 3.0 250.0 20.8 2.1 4.7 MWM0503 ML05 R 32.0 60.0 14.0 31.0 MPCN300C02-TX5020

T2421116 MPNHR20-4 4.0 160.0 15.8 2.9 6.0 MWM0502 ML05 R 20.0 40.0 9.0 25.0 MPCN400C03-TX5020

T2421117 MPNHR25-4 4.0 200.0 17.5 2.9 5.2 MWM0503 ML05 R 25.0 40.0 11.5 25.0 MPCN400C03-TX5020

T2421118 MPNHR32-4 4.0 250.0 20.8 2.9 4.7 MWM0503 ML05 R 32.0 60.0 14.0 31.0 MPCN400C03-TX5020

T2421119 MPNHL16-2 2.0 125.0 16.5 1.8 8.5 MWM0501 ML05 L 16.0 - 7.5 25.0 MPCN200C02-TX5020

T2421120 MPNHL20-2 2.0 160.0 15.8 1.6 6.0 MWM0502 ML05 L 20.0 40.0 9.0 25.0 MPCN200C02-TX5020

T2421121 MPNHL25-2 2.0 200.0 17.5 1.6 5.0 MWM0503 ML05 L 25.0 40.0 11.5 25.0 MPCN200C02-TX5020

T2421122 MPNHL32-2 2.0 250.0 20.8 1.5 4.7 MWM0503 ML05 L 32.0 60.0 14.0 31.0 MPCN200C02-TX5020

T2421123 MPNHL20-3 3.0 160.0 15.8 2.1 6.0 MWM0502 ML05 L 20.0 40.0 9.0 25.0 MPCN300C02-TX5020

T2421124 MPNHL25-3 3.0 200.0 17.5 2.1 5.1 MWM0503 ML05 L 25.0 40.0 11.5 25.0 MPCN300C02-TX5020

T2421125 MPNHL32-3 3.0 250.0 20.8 2.1 4.7 MWM0503 ML05 L 32.0 60.0 14.0 31.0 MPCN300C02-TX5020

T2421126 MPNHL20-4 4.0 160.0 15.8 2.9 6.0 MWM0502 ML05 L 20.0 40.0 9.0 25.0 MPCN400C03-TX5020

T2421127 MPNHL25-4 4.0 200.0 17.5 2.9 5.2 MWM0503 ML05 L 25.0 40.0 11.5 25.0 MPCN400C03-TX5020

T2421128 MPNHL32-4 4.0 250.0 20.8 2.9 4.7 MWM0503 ML05 L 32.0 60.0 14.0 31.0 MPCN400C03-TX5020
